Hand-Drawn Lightweight Drapery Track - AP 1005
AP 1005 offers a subtle, elegantly curved narrow drapery track profile ideal for lightweight curtains. Its understated size makes it a preferred choice for applications such as inner curtains.
The AP 1005 is produced using aluminum made with post-consumer recycled scrap, supporting a more resource-conscious approach to production while maintaining the quality and performance expected of the track.
- Ceiling, Suspended and Wall Mounts available.
- Suitable for custom bends but not curves.
- Ask about bulk order options.
Gliders provided for WAVE or pleated drapery panels.
External Dimensions: 10.50 x 14.50h mm
| Max Single Length | Max Weight | Bending Radius |
|---|---|---|
| 10 - 600 cm | 8.5 kg/600cm | Min. 10 cm |
Fabric and drapery panel construction must be considered when discussing allowable weights.
NOTE: If track is bent or curved, the weight allowance is reduced 50%. Multiple tracks may be joined to mount wider installations.
Metal Finishes:
Powder coating and wet lacquering in all RAL and standard NCS colors is possible
Hover on tile for color name.
